Features

Satosen’s pattern designs aimed at printed circuit boards enabled for substantial electrical currents help ensure the authenticity of circuits and components, making it possible to elicit superior qualities.
Uneven patterns are completely covered by solder resists that Satosen creates by patterning and spray coating at a conductor thickness of 300 µm.
NOTE: Please feel free to contact us for more information on conductor thickness.

Printed Circuit Boards Enabled for Substantial Electrical Currents
